12-inch coverage for flashing transitions
Key features
Self-adhered butyl system for air and water sealing
Designed for integration with Tyvek WRB systems
Technical specifications
| Width | 12.0 in |
|---|---|
| Length | 900.0 in |
| Material | Polypropylene film with 100% butyl adhesive |
| Application area | Window and door flange flashing, wall transitions |
Product details
Large and complex transitions can overwhelm standard flashing widths, creating excessive seams that raise leak risk over time. Tyvek Flashing Tape 12 in x 75 ft provides extra-wide coverage for these demanding conditions, including deep returns and broader interface zones.
The 12-inch format is often chosen to simplify detailing where multiple narrower strips would otherwise be required. Reducing seam count can improve reliability and speed, especially on high-volume opening schedules with complex geometries.
With wider products, layout planning becomes even more important: alignment, wrinkle control, pressure setting, and drainage direction all need active field management. Wider tape can improve coverage, but poor sequencing still leads to failure pathways.
For spec-driven jobs, treat this product as part of a system, not a standalone fix. Pair with compatible WRB components and follow manufacturer requirements for substrate prep, overlap strategy, and exposure constraints.
Documents & certifications
Technical data sheet
Manufacturer-tested R-value, coverage, fire notes, and handling—use for submittals, RFIs, and field QA.
